Graphtec GL900-4 4 ch Hi-Speed midiLogger
Graphtec GL900-4 4 ch Hi-Speed midiLogger
Graphtec GL900-4 4 ch Hi-Speed midiLogger
Product ID :
Price :
Updated :
Quantity :
1 piece
Status :
Brand :
Link :
Manual/Product reference :
  Tell a Friend

GL900-4 High-speed isolated 4-channel multifunction logger



Item Description
 No. of analog input ch. 4ch
 External input/output  Trigger input (1 channel), Logic input (4 channels) or Pulse input (4 channels),  Alarm output (4 channels)
 Sampling interval  10μs to 1 min
 TIME/DIV  10 ms/DIV to 24 hour/DIV
 Timer functions  Date and time, daily cycle, hourly cycle
 Trigger  functions  Type  Start: Data capture starts when a trigger is activated; Stop: Data capture stops  when a trigger is activated
 Condition  Start: Off, Input signal level (analog, logic/pulse), External*1, Scheduled time
 Stop: Off, Input signal level (analog, logic/pulse), External *1, Scheduled time
 Combination  Input signal level: Level OR, Level AND, Edge OR, Edge AND
 Mode  H (Rising), L (Falling), Window In*2, Window Out*2
 Alarm setting functions  Rising, Falling, Window In*2, Window Out*2
 Alarm output *1  Number of channels: 4, Open collector output (5V, 10 kΩ pull-up resistance)
 Pulse  input*1, *3  RPM mode  50 to 20 M RPM/F.S. (in steps of 1, 2, or 5)
 Count mode  50 to 20 M C/F.S. (in steps of 1, 2, or 5)
 Inst. Mode  50 to 20 M C/F.S. (in steps of 1, 2, or 5)
 Calculation functions  Statistical calculations *4: Average, Peak, Maximum, Minimum, RMS (2  calculations can be set simultaneously)
 Other functions  Search function, annotation input function
 PC inteface  Ethernet (10BASE-T/100BASE-TX), USB (High Speed supported) provided as  standard
 Ethernet functions  Web server function, FTP server function, NTP client function
 USB function  USB drive mode (File transfer and deletion from internal GL900 memory)
 Memory  device  Internal  One million data points / Internal flash memory:Approx. 256 MB
 External  USB memory slot (High speed supported) *5
 Display screens  Waveforms + digital values, enlarged waveforms, digital values + calculation  results, X-Y
 Display unit  5.7-inch TFT color LCD
 Operating environment  0 to 40℃, 5 to 85% R.H. (15 to 35℃ when using batteries)
 Withstand voltage  Between each input channel and GND: 1000 V p-p for one minute, between input  terminals: 1000 Vp-p for one minute
 Power  supply  AC adapter  100 to 240 VAC, 50 to 60 Hz
 DC input  8.5 to 24 VDC
 Battery pack  *6  Option
 Power consumption  40VA (when operating and charging battery with AC power)
 External dimensions  232 x 150 x 80 mm (W x H x D), approx.
 Weight (approx.)  1.0 kg (excluding AC adapter and battery)
 Vibration-tested  conditions  Equivalent to automobile parts Type 1 Category A classification
